ASUS ROG STRIX Z790-A GAMING WIFI II LGA1700

Product Description:

The ASUS ROG STRIX Z790-A GAMING WIFI II motherboard supports Intel 12th, 13th, and 14th Gen processors with DDR5 memory up to 192GB. It delivers high performance with PCIe 5.0 support, extensive M.2 storage, and advanced connectivity including Wi-Fi and high-speed USB options.

Key Features:

• Socket: LGA1700
• Chipset: Intel Z790
• Memory Type: DDR5/DIMM, 4 x Slots, Max 192GB
• Processor Support: Intel Core 14th, 13th, 12th Gen
• Expansion Slots: 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
• Storage: 5 x M.2 slots, 4 x SATA 6Gb/s
• USB Ports: 1 x USB 20Gbps, 3 x USB 10Gbps, 4 x USB 5Gbps, 4 x USB 2.0 (Rear); 1 x USB 20Gbps, 1 x USB 5Gbps, 2 x USB 2.0 (Front)
• Back I/O Ports: 1 x USB 20Gbps; 3 x USB 10Gbps; 4 x USB 5Gbps; 4 x USB 2.0; 1 x DisplayPort; 1 x HDMI; 1 x Wi-Fi module; 1 x Intel 2.5Gb Ethernet; 2 x Audio jacks; 1 x Optical S/PDIF out; 1 x BIOS FlashBack button; 1 x Clear CMOS button
• Internal I/O Ports: 1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 1 x 4-pin AIO Pump header; 5 x 4-pin Chassis Fan headers; 1 x 24-pin main power connector; 2 x 8-pin +12V power connector; 5 x M.2 slots; 4 x SATA 6Gb/s ports; 1 x USB 20Gbps connector; 1 x USB 5Gbps header; 2 x USB 2.0 headers; 3 x Addressable Gen 2 headers; 1 x Aura RGB header; 1 x CPU Over voltage jumper; 1 x Front panel audio header; 1 x 20-3 pin system panel header; 1 x Thermal sensor header; 1 x Thunderbolt header
• Form Factor: ATX
• Warranty: 1 Year

[p/n 90MB1FN0-M0EAY0] SKU: I31031
